High usable capacity: 95% depth of discharge (DOD). Long cycle life: a cycle life of more than 8,000 times. Solar Inverter Compatibility: Compatible with most solar inverters. Communication support: Supports CAN and RS485 communication After-Sales Support: Enjoy free lifetime after-sales support. Long-term warranty: 10-year warranty product guarantee
| Model | EV-5.12N |
| Total Energy [kWh] | 5.12 |
| Capacity [Ah] | 100 |
| Nominal Voltage [V] | 51.2 |
| Voltage Range [M] | 48V-51.2V |
| MAX.Charge & Discharge Current[A] | 60 |
| Dimension[W×DxH,mm] | 660*430*185 |
| Net Weight [Kg] | 44 |
48V 100AH lithium battery has high energy density, can provide longer battery life, and is suitable for long-term energy storage needs.
Lithium batteries have excellent power output capabilities and can quickly release electrical energy to meet high power output requirements. This is very important for some application scenarios that require high power output in a short period of time, such as commercial PV energy storage systems.
Our products meet international quality standards and are backed by certifications such as UL, CE, UN38.3, MSDS, IEC, and ISO. These certifications ensure that our products are safe, reliable, and adhere to rigorous industry regulations.
| Model | EV-5.12N | EV-10.24N | EV-15.36N |
| Total Energy [kWh] | 5.12 | 10.24 | 15.36 |
| Capacity [Ah] | 100 | 200 | 300 |
| Nominal Voltage [V] | 51.2 | 51.2 | 51.2 |
| Voltage Range [V] | 48-57.6 | 48-57.6 | 48-57.6 |
| MAX. Charge & Discharge Current [A] | 60 | 100 | 150 |
| Peak Charge & Discharge Current [A] (for 10 sec.) | 100 | 120 | 200 |
| Product Dimension(MM) | 660×430×185MM | 830×610×194MM | 905×470×250MM |
| Net Weight [Kg] | 44 | 86 | 120 |
| Scalable | 1~16in parallel | ||
| Communication | CAN,RS485 | ||
| Communicated Inverter | GOODWE/Victron/SOFAR/DEYE/Growatt/MEGAREVO/SRNE | ||
| Enclosure Protection Rating | IP21 | ||
| Charging Temp Range [°c] | 0~55 | ||
| Discharging Temp Range [℃] | -10 ~55 | ||
| Cycle Life | ≥8,000 Cycle@ 80% DOD / 25℃ / 0.5C, 60%EOL | ||
| Warranty | 10 years | ||
| Certification | IEC62619,UN38.3,CE | ||
