EV-3.84N Series: An Intelligent Energy Solution. Unlock efficient energy storage, a steadfast power supply, peak demand smoothing, and unwavering performance with our cutting-edge energy storage solution. Tailor its configuration to your requirements, backed by the Smart BMS for enhanced safety and efficiency. Embrace sustainable energy choices through eco-friendly technology. The EV 12V Series—where smart design meets reliable, adaptable, and environmentally conscious energy solutions.
| Model | EV-3.84N |
| Total Energy [kWh] | 3.84 |
| Capacity [Ah] | 300 |
| Nominal Voltage [V] | 12.8 |
| Voltage Range [M] | 12-14.4 V |
| MAX.Charge & Discharge Current[A] | 150 |
| Dimension[W×DxH,mm] | 385*205*315 |
| Net Weight [Kg] | 28 |
Our 12V lithium energy storage batteries excel in energy density, compactly storing a substantial amount of electrical energy for space-efficient storage.
Supporting a Depth of Discharge (DOD) of over 90%, these lithium batteries provide increased usable capacity, catering to applications requiring uninterrupted power output.
In contrast to alternatives such as lead-acid batteries, lithium batteries showcase an extended cycle life, enduring more than 6,000 charge and discharge cycles, ensuring sustained reliability.
| Model | EV-3.84N |
| Total Energy [kWh] | 3.84 |
| Capacity [Ah] | 300 |
| Nominal Voltage [V] | 12.8 |
| Voltage Range [V] | 10.5-14.4 |
| MAX. Charge & Discharge Current [A] | 150 |
| Dimension[W×D×H,mm] | 385*205*315 |
| Net Weight [Kg] | 28 |
| Scalable | UP to 4 inseries and 6 in parallel |
| Communication | Bluetooth |
| Enclosure Protection Rating | IP21 |
| Working Temperature Range[℃] | -10~50 |
| Cycle Life | >6000 Cycle@80%DOD/25℃/0.3C，60%EOL |
| Warranty | 5 years |
| Certification | IEC62619,UN38.3,CE |
